FEATURES

- Size; 1600 mm, 1800 mm, 2000 mm
- 85 Akis / 35 mm
- Standard Pin
- Groove measurement must be Min. 16x230 mm.
- Reversable latch
- Locking ability with low power
- Downwards movement of the locking cam prevents sash drop
- Variable handle position
- Surface plating: Metal
- Back Set: 35 mm
- Centre length 85 conforming the EU standards
- Six point locking
- Marks; WBOSS or WORK
Code
Size
Package
Gross Weight
KI-001
1600 mm
20 Pcs.
25,00 Kg
KI-002
1800 mm
20 Pcs.
26,00 Kg
KI-005
2000 mm
20 Pcs.
26,50 Kg


m3
